European to Chinese DC (CCS2-GBT)

Startseite - Products - European to Chinese DC (CCS2-GBT)

European to Chinese DC (CCS2-GBT)

  • Rated Current: Max 250A
  • Rated Voltage: Max 1000V DC
  • Working Temperature: -30°C to +50°C
  • Dimensions: 294*95*145mm
  • Customization: color, logo, package

Share:

Introduction to European to Chinese DC (CCS2-GBT)

Reliable and easy to use, the CCS2 to GBT DC charging adapter allows vehicles with Chinese standard port (GBT) to fast charge using European standard DC chargers (CCS2). The product has a compact design for easy storage and is plug-and-play without needing additional setups. Comes with IP54 water resistance and temperature endurance of -30°C to +50°C for safety and durability that you can trust.

Features of Mekel EV charging adapters

A Solution for Every Charging Standard

Mekel’s EV charging adapter lineup provides conversion solutions for every charging standard across the world, including conversions between American Type 1, Tesla NACS, European Type 2, Chinese GBT, and Japanese Chademo charging ports.  Speak with us to find out about the perfect adaptor products for your respective markets

Premium Built Quality

Our charging adapters are made with high-strength thermoplastic shell that provide great durability and silver-plated copper alloy that delivers top-class conductivity, which will help drive your customers’ satisfaction

Easy to Use and Travel With

Our EV charging adapters boast compact designs without compromising functionality. It supports high speed AC or DC charging, all while fits comfortably inside a glovebox. Simply fit onto the charging gun and plug into vehicle’s charging port fora seamless charging experience

Product Highlight

  • All Charging Standards
  • Premium Materials
  • Weather Protection
  • Production Readiness
  • Fast Delivery

Product Specifications

Product NameCCS2 to GBT Charging Adapter
Rated CurrentMax 250A
Rated Voltage Max 1000V DC
Water ResistanceIP54 (when plugged)
Outer Shell Thermoplastic(TBC)
Conducting PinCopper alloy, Silver-plated
Working Temperature -30°C to +50°C
Net Weight1.6kg
Dimensions294*95*145mm

FAQ

Q: Will this European to Chinese DC adapter charge slower than the original one?
A: This product uses silver-plated copper alloy conductors (resistance < 0.2mΩ), power loss < 0.3%, and charging efficiency is equivalent to direct charging piles.

Q: What safety certifications has this CCS2-GBT DC charging adapter passed?
A: It holds CE/ROHS certification, and core components have passed ISO 20653 dust and water resistance test and UL94 V-0 flame retardant certification.

Q: How much power does this CCS2-GBT charging adapter support for fast charging?
A: This product supports up to 250A/1000V DC fast charging (250kW), meeting the extreme speed charging needs of mainstream models.

Q: Can this European to Chinese DC adapter be used normally in a low temperature environment of -20℃?
A Yes, this EV charging adapter has passed the -30℃ extreme cold test, and the built-in temperature sensor is used for real-time monitoring to ensure safe operation in the full temperature range of -30°C to 50°C.
