Carregador VinFast

VinFast Charger is a compact and efficient AC charging solution designed specifically for home and workplace electric vehicle charging. Unlike DC fast chargers that require high-power infrastructure, the VinFast Charger delivers AC power directly to the vehicle’s onboard charger, which then converts it to DC for battery storage.

The VinFast Charger is ideal for overnight charging, typically adding 40-50 kilometers of range per hour. For most daily driving needs, a VinFast Charger can fully charge an EV in 6-8 hours, making it the perfect solution for residential garages, office parking lots, and apartment complexes.

Key Features of VinFast Charger

Reliable Daily Charging

The VinFast Charger provides steady output, ensuring your EV is ready each morning. It is compatible with all major EV brands using Type 1, Type 2, or NACS connectors.

Conectividade inteligente

Integrated with Wi-Fi and Bluetooth, the VinFast Charger supports remote monitoring, scheduled charging, and energy usage tracking via a mobile app.

Compact & Weatherproof Design

With IP54 protection rating, the VinFast Charger is built for both indoor and outdoor installation. Its compact size allows for easy wall mounting in tight spaces.

Advanced Safety Protection

The VinFast Charger includes built-in protection against over-voltage, under-voltage, over-current, short-circuit, and leakage (Type A RCD + 6mA DC detection).

Interface de fácil utilização

LED indicator lights and optional RFID card reader make the VinFast Charger easy to use for homeowners, tenants, or shared parking users.

Global Certifications

CE, RoHS, and IEC 61851 compliant.

Parameter of VinFast Charger

Caraterística	Especificação
Nome do produto	Carregador VinFast
Tensão de entrada	220V-240V AC (Single-phase, ±10%)
Potência de saída	7kW (Adjustable: 3.5kW / 7kW)
Corrente de saída	32A (Maximum)
Tipos de conectores	Type 1 (SAE J1772) / Type 2 (IEC 62196) / NACS
Comprimento do cabo de carregamento	5m (padrão) / 7m / 10m (personalizável)
Eficiência	≥ 98% at nominal output power
Interface do utilizador	LED Indicators + RFID Card Reader (Optional)
Comunicação	Wi-Fi / Bluetooth / 4G (Optional) / OCPP 1.6J
Material do invólucro	PC + ABS (Flame-retardant) / Aluminum Alloy
Grau de proteção	IP54 (Outdoor rated)
Temperatura de funcionamento	-25°C a +50°C
Dimensions (W×H×D)	250×350×120mm
Tipo de montagem	Wall-mounted / Pedestal-mounted (Optional)

Amplie a sua infraestrutura de VE com soluções de carregamento de elevada eficiência

Why Choose Mekel's VinFast Charger

Perfect for Home Use

The VinFast Charger is designed for overnight charging — plug in when you get home, wake up to a full battery. No complicated installation or grid upgrades required.

Cost-Effective Solution

Compared to DC fast chargers, the VinFast Charger costs significantly less to purchase and install. It runs on standard household single-phase power, reducing electrical work expenses.

Smart Charging Features

Schedule charging during off-peak electricity rates, monitor energy consumption, and control access via app. The VinFast Charger helps you save money and manage charging intelligently.

Easy Installation & Support

Our VinFast Charger comes with a standard mounting template and wiring diagram. Most electricians can complete installation in under 2 hours. We also provide 24/7 technical support and a 3-year warranty.

Aplicação

Mekel’s VinFast Chargers are versatile and engineered for high-traffic environments:

FAQ

What type of electric vehicles are compatible with the VinFast Charger?

The VinFast Charger is compatible with all major EV brands that use Type 1, Type 2, or NACS connectors. The VinFast Charger works seamlessly with most passenger electric vehicles on the market today.

Can the VinFast Charger be installed outdoors?

Yes, the VinFast Charger has an IP54 weatherproof rating, making it suitable for outdoor installation in rain, snow, or dust. The VinFast Charger is built to withstand various weather conditions.

Does the VinFast Charger support scheduled charging?

Yes, the VinFast Charger allows you to set charging schedules via its mobile app. You can program your VinFast Charger to charge only during off-peak hours to save on electricity costs.

How long does it take to install the VinFast Charger?

Installation of the VinFast Charger typically takes 1-2 hours for a qualified electrician. The VinFast Charger comes with a standard mounting template and clear wiring instructions.

What is the warranty period for the VinFast Charger?

The VinFast Charger comes with a standard 3-year warranty. Mekel also provides 24/7 technical support for any questions regarding your VinFast Charger.
